Airton Wall-Mounted Air Conditioner with Heat Pump
Airton Wall-Mounted Air Conditioner with Heat Pump Bisplit (x2)
Airton Wall-Mounted Air Conditioner with Heat Pump Trisplit (x3) (HP)
Airton Wall-Mounted Air Conditioner with Heat Pump Quadrisplit (x4) (HP)
Choose your model
A Monosplit air conditioner consists of one indoor unit connected to an outdoor unit.
A Bisplit air conditioner includes two indoor units connected to a single outdoor unit.
A Trisplit air conditioner includes three indoor units connected to a single outdoor unit.
A Quadrisplit air conditioner includes four indoor units connected to a single outdoor unit.
• Power level :
Select power level
A power level of 2500W is suitable for spaces up to 30m².
A power level of 3400W is suitable for spaces up to 40m².
A power level of 5270W is suitable for spaces up to 60m².
• Connection :
• Connection :
Select power level
A connection links an indoor unit to an outdoor unit. It is recommended not to exceed 12 meters with 4m or 6m lines. For connections longer than 8 meters, the lines will be joined using a union fitting.
• Wi-Fi Module :
Connect your air conditioner
The Wi-Fi module integrates with your air conditioner. Schedule and adjust the temperature of your home directly from your smartphone wherever you are. Enjoy immediate thermal comfort when you arrive while saving up to 25% on energy costs.
• Power level :
Select power level
A combined power level of 2600W and 2600W, perfect for two rooms with different needs of 30m² each, for a total surface area of around 60m².
A combined power level of 2600W and 3400W, perfect for two rooms with different needs of 30m² and 40m², for a total surface area of around 70m².
• Connection 1 :
• Connection 2 :
Add your refrigerant lines
A connection links an indoor unit to an outdoor unit. It is recommended not to exceed 12m with 4m or 6m lines. For connections longer than 8m, the lines will be joined using a union fitting.
• Wi-Fi Module :
Connect your air conditioner
The Wi-Fi module integrates with your air conditioner. Schedule and adjust the temperature of your home directly from your smartphone wherever you are. Enjoy immediate thermal comfort when you arrive while saving up to 25% on energy costs.
• Power level:
Power level
A trisplit configuration with:
• 2 units of 2600W (maximum area of 30m² each)
• 1 unit of 3500W (maximum area of 40m²)
Ideal for 3 rooms of different sizes. You benefit from
optimal comfort across a total area of around 100m².
• Connection 1 :
• Connection 2 :
• Connection 3 :
Add your refrigerant lines
A refrigerant line connects the indoor unit to the outdoor unit. We recommend not exceeding 12 metres in total length, using 4m or 6m ReadyClim lines. For connections over 8 metres, the lines should be joined using a union fitting.
• Wi-Fi Module :
Connect your air conditioner
The Wi-Fi module integrates with your air conditioner. Program and adjust the temperature of your home from your smartphone wherever you are. Enjoy immediate thermal comfort upon arrival while saving up to 25% on energy costs.
• Power level :
Power level
A quadrisplit configuration with:
• 3 units of 2600W (maximum surface area of 30m² each)
• 1 unit of 3500W (maximum surface area of 40m²)
Ideal for 4 distinct rooms, for a total surface area of
around 130m².
• Connection 1 :
• Connection 2 :
• Connection 3 :
• Connection 4 :
Add your refrigerant connections
A connection links an indoor unit to an outdoor unit. It is recommended not to exceed 12m with 4m or 6m connections. For a connection longer than 8m, the lines will be joined using a union fitting.
• Wi-Fi Module :
Connect your air conditioner
The Wi-Fi module integrates with your air conditioner. Schedule and adjust the temperature of your home directly from your smartphone wherever you are. Enjoy immediate thermal comfort when you arrive while saving up to 25% on energy costs.
Product Details
Powerful and discreet wall-mounted air conditioner with heating and cooling functions. Adjustable temperature range from 16°C to 31°C. Energy efficiency rated A++ (cooling) and A+ (heating). Includes both indoor and outdoor units. Programmable system with 5 operating modes. Compatible with the ReadyClim plug-and-play solution and the SmartLife Wi-Fi module.
| Specifications | Details |
|---|---|
| Cooling/Heating Capacity | 2500W / 2800W 3600W / 3400W 5270W / 5500W |
| Indoor Airflow | 520 m³/h 580 m³/h 850 m³/h |
| Connection Diameter | 1/4 3/8 1/4 3/8 1/4 1/2 |
| Recommended Circuit Breaker | 16A Type D 16A Type D 20A Type D |
| Compressor Brand | GMCC GMCC GMCC |
| Weight | 9 + 27 kg net 9 + 29 kg net 13 + 40 kg net |
| Sound Pressure Level | 19/52 dB 20/53 dB 29/55 dB |
| Power | 2500 W 3400 W 5270 W |
| R32 Gas Quantity | 0.55 kg 0.6 kg 0.98 kg |
| SEER / SCOP | 6.1 / 4 6.5 / 4 6.3 / 4 |
| Area Coverage | Up to 30m² (80m³) Up to 40m² (105m³) Up to 60m² (150m³) |
| Split Type | Monosplit |
| Wi-Fi | Compatible with Wi-Fi module |
Product Details
Powerful and discreet fixed bi-split air conditioner with heating and cooling functions...
| Specifications | Details |
|---|---|
| Cooling/Heating Capacity | 2600w/2800w - 2600w/2800w 2600w/2800w - 3500w/3650w |
| Indoor Airflow | 520 m³/h - 580 m³/h 520 m³/h - 580 m³/h |
| Connection Diameter | 1/4 3/8 1/4 3/8 |
- 2 Indoor Units
- 1 Outdoor Unit
- 2 Remote Controls with Batteries
- 2 Condensate Pipes (4 meters)
- 1 Insulating Tape
- 1 Wall Outlet
- 4 Anti-Vibration Blocks
- 2 Electrical Cables (6 meters)
- 2 Connector Protection Foams
Product Details
Powerful and discreet fixed tri-split air conditioner with heating and cooling functions. Temperature adjustable between 16°C and 31°C. Energy efficiency rated A++ and A+. Includes three indoor units + one outdoor unit. Programmable air conditioning system with 5 operating modes. Compatible with the ReadyClim plug-and-play solution. High-performance system suitable for areas up to 100m². The tri-split system can heat and cool an entire home. Enjoy consistent and even comfort all year round. Each indoor unit operates independently for easy regulation. Three rooms of your choice can benefit from reversible air conditioning.
| Specifications | Details |
|---|---|
| Cooling/Heating Capacity | 2600W/2800W - 2600W/2800W - 3500W/3650W |
| Indoor Airflow | 520 m³/h - 520 m³/h - 580 m³/h |
| Connection Diameter | 1/4 3/8 |
| Recommended Circuit Breaker | 25A Type D |
| Compressor Brand | Panasonic |
| Weight (int1+int2+ext) | 9 - 9 - 10 - 55 kg net |
| Sound Pressure Level | 21 / 21 / 22 / 52 dB |
| Power | 2600W / 2600W / 3500W |
| R32 Gas Quantity | 1.5 kg |
| SEER / SCOP | 6.1 / 4 |
| Area Coverage | 30m² + 30m² + 40m² |
| Split Type | Trisplit |
| Wi-Fi | Compatible with Wi-Fi module |
Product Details
Powerful and discreet fixed quadri-split air conditioner with heating and cooling functions. Temperature adjustable between 16°C and 31°C. Energy efficiency rated A++ and A+. Includes three indoor units + one outdoor unit. Programmable air conditioning system with 5 operating modes. Compatible with the ReadyClim plug-and-play solution. High-performance system suitable for areas up to 100m². The quadri-split system can heat and cool an entire home. Enjoy consistent and even comfort all year round. Each indoor unit operates independently for easy regulation. Three rooms of your choice can benefit from reversible air conditioning.
| Specifications | Details |
|---|---|
| Cooling/Heating Capacity | 3500/3650W - 2600/2800W - 2600/2800W - 2600/2800W |
| Indoor Airflow | 580 - 520x3 m³/h |
| Connection Diameter | 1/4 3/8 |
| Recommended Circuit Breaker | 25A Type D |
| Compressor Brand | Panasonic |
| Weight (int1+int2+ext) | 9 - 9 - 9 - 10 - 68 kg net |
| Sound Pressure Level | 21 / 21 / 22 / 55 dB |
| Power | 3500W / 2500W - 3500W / 2500W - 3500W / 2500W |
| R32 Gas Quantity | 2 kg |
| SEER / SCOP | 6.1 / 4 |
| Area Coverage | 40m² + 30m² x3 |
| Split Type | Quadrisplit |
| Wi-Fi | Compatible with Wi-Fi module |
